Vendor: Mini Skid Upgrades
Type: N/a
Sku: sku-44529780097232
A double Inlet, double outlet, tandem pump-gear pump designed to fit AGT K models with an offset, belt drive hydraulic pump.
This pump comes with M30 and M22 inlet and outlet adapters to fit the factory lines. One supply line needs to be modified and shortened and the location of the hydraulic filter moved slightly to accommodate the larger and longer pump.
Specs:
9.5/9.5 cc/rev front to rear, 19cc/rev total Displacement (1.16 cubic inches / rev)
2 SAE 12 Inlets
2 SAE 10 Outlets
SAE 16/32DP 9T Shaft
SAE "A" 2 Bolt Flange
18GPM @ 3600 RPM & 2250PSI, 4000 RPM Max.
Clockwise Rotation
12 Month Warranty
This unit has not been tested on machines with direct-drive pumps (pumps mounted directly on the engine shaft) and may be too high displacement for a directly mounted setup.
We recommend sizing up.
